optical spectrum analyzer

Key Features Wavelength Range: 350 nm to 1000 nm Wavelength Resolution (at 650 nm): 0.05 nm (standard), 0.01 nm (option) Peak Wavelength Measurement Resolution: 0.001 nm Wavelength Measurement Accuracy: ±0.05 nm (standard), ±0.01 nm (option) Coherence Measurement Resolution: 0.001 mm Coherence Measurement Length: Approx. 10 mm (standard), Approx. 40 mm (option) Maximum Input Level: ±10 dBm Level Sensitivity: -80 dBm to +20 dBm Dynamic Range: 60 dB Sweep Time: 1 ms to 500 ms Measurement Speed: Fast sweep option of 0.5 s for full-span measurements Display: 8.4-inch color LCD Interfaces: GPIB, RS-232C, Ethernet Power Supply: 100-240 V AC, 50/60 Hz Dimensions: 426 mm (W) × 173 mm (H) × 546 mm (D) Weight: Approximately 18 kg Additional Characteristics Uses a built-in He-Ne laser as a wavelength reference source to ensure high wavelength measurement accuracy Effective for evaluating CD/DVD laser diodes as well as blue-violet laser diodes Ideal for evaluating temperature characteristics of system components due to fast measurement speed Suitable for manufacturing and production environments with high throughput capabilities Small and lightweight platform
