Spectrum analyzer cabinet

Key Features Integrated Mainframe and Display – Combines a 4-slot module mainframe with a full-color CRT display in a single unit, eliminating the need for a separate display and mainframe chassis. Four Module Slots – Accommodates up to four HP 70000 series plug-in modules simultaneously, allowing flexible system configuration. Full-Color CRT Display – Provides high-quality color graphical display of test results, traces, and measurement data. Removable Custom Hardkey Panel – Features an interchangeable custom hardkey panel that can be replaced or customized for different instrument configurations. Multi-Instrument Control – Supports control of up to four modular instruments displayed simultaneously on the screen. The INSTR key allows the operator to switch control from one instrument to another with a single keystroke. MMS (Modular Measurement System) Instrument Selection – Includes a dedicated key to aid in selecting the MMS instrument to be controlled. Advanced Firmware Features – Equipped with several advanced firmware capabilities for enhanced system operation and measurement functionality. HP-IB (GPIB) Interface – Sends displayed graphics directly to an HP-IB printer or plotter for hard-copy documentation. HP PaintJet Printer Support – Supports HP PaintJet color printers, enabling full-color printed documentation of test results. HP-HIL Keyboard Connector – Front-panel HP-HIL connector allows attachment of an HP 46021A or 98203C keyboard for front-panel system control, entering user titles, spectrum analyzer commands, and small downloadable programs (DLPs). System Expandability – Connects to HP 70001A mainframes to create larger, more complex measurement systems. Memory Card and Mass Storage Capabilities – Supports memory card and mass storage for saving and recalling instrument states and measurement data.
