E4990A Impedance Analyzer

Whether your application is in R&D, production, quality assurance, or incoming inspection, we take pride in contributing to your success. Features： Five upgradable frequency options; 20 Hz to 10/20/30/50/120 MHz Basic impedance measurement accuracy of ±0.08% (±0.045%, typ) 25 mΩ to 40 MΩ wide impedance measurement range (10% measurement accuracy range) Measurement parameters: |Z|, |Y|, θ, R, X, G, B, L, C, D, Q, Complex Z, Complex Y, Vac, Iac, Vdc, Idc Built-in DC bias range: 0 V to ±40 V, 0 A to ±100 mA
